5000L Beer brewery equipment, brewing system, factory beer plant

Model No.︰

RM5000L

Brand Name︰

RAINBOW

Country of Origin︰

China

Unit Price︰

US $ 109999 / pc

Minimum Order︰

1 pc

Share on:

Product Description

Company Profile:

We, Jinan Rainbow Machinery Co., Ltd  are a professional manufacturer and leading supplier of good quality beer brewing system, ranging from 100L-20000L per batch (used for home, pub/hotel, factory, etc.) at a very competitive price, with product design, production, sales, and installation support.



                                                         Professional factory beer brewing equipment

 MAIN CONFIGURATIONS:

Brewhouse system:

  • 7-vessel

1) - inner wall stainless steel 304, 3mm;

    - surface wall stainless steel 304, 2mm

2) Dome top, top manway with glass

    Side manway, cone bottom 160 degree

3) - insulation: polyurethane/rockwool 100mm;

     - with inside CIP washing ball

     - rake

     -agitator

     - removable false bottom

    - sparging arm, sight glass

      -Tangentiainlet for whirlpool

      -Thermowell for temperature sensor and thermometer....



Fermentation system:

1) - Inner wall stainless steel 304, 3mm;

      surface wall stainless steel 304, 2mm

 2) Dome top, conical bottom,

      -Side mounted manway

3) -Insulation: polyurethane 100mm

4) -Glycol cooling jackets on both cylinder and cone

5) - Inside 360 degree rotating CIP washing ball;

     - CIP arm

     - Pressure gauge

     - safety&vacuum va e on top

      - sample va e

     - rotating racking arm

     - thermometer

      -carbonation stone (optional)

     - dry hops port on top

 6)  -100% TIG welding with pure argon gas shield

       -Interior Finish:Mirror polishing to 0.4~0.6μm without dead corner

      -Testing pressure: 3 bar

      -working pressure: 1.5-2 bar



For Your  Information:

 1. We have the capacity of 100L, 200L, 300L, 500L, 1000L, 2000L, 3000L, 5000L, 8000L...( 1bbl,       2bbl, 5bbl, 10bbl....) per patch for your reference.

      It can be customized, such as the capacity, material, voltage(like 380v, 50Hz, 3phases),    heating source, etc.

 2. The brewer can also brew draft beer, pale beer, brown beer, stout beer etc,

      to meet different taste of customers.

 OPTIONAL:

 Beer bottling line: bottle washing machine, filling machine, capping machine,

 pasteurization tank, labelling machine.

 Kegs washer and filler.

 Beer kegs(10L,20L,30L,50L...),  beer tower.

 Steam boiler.

5000L Microbrewery equipment, brewing system, beer machine



Payment Terms︰ TT/LC
