About us:
1. For electric machine parts, we use SIEMENS, SCHNEIDER, DANFOSS, OMRON, ABB....etc. Also UL standard.
2. We have the capacity of 100L, 200L, 300L, 500L, 1000L, 1200L, 2000L, 3000L, 5000L, 8000L...(1bbl, 2bbl, 5bbl, 10bbl....) per patch for your choice.
It can be customized, such as the capacity(dimension can be customized), material(stainless steel 304/316 or copper), voltage(like 380v, 50Hz, 3phases), heating source(electric, steam or gas fired heating), etc.
♦ Engineers are available for Overseas service. Provide installation, commissioning/testing, maintaining and personal training, beer production technology.
MAIN CONFIGURATIONS:
The 1000L brewing system configuration for your reference.
|
Items
|
Equipment
|
Specification
|
Quantity
(PCS)
|
|
Malt miller
|
Malt miller
|
300kg/h
|
1
|
|
Brewhouse
|
Mash tun/lautering tun
|
1000L
|
1
|
|
Brew kettle/whirlpool
|
1000L
|
1
|
|
Hot liquor tank
|
2000L
|
1
|
|
Plate heat exchanger
|
10 m2
|
1
|
|
Pump
|
3 m³/h
|
2
|
|
Working platform
|
|
1
|
|
Fermentation
|
Fermenter
|
1000L
|
6
|
|
Aeration&yeast adding tank
|
30L
|
1
|
|
Cooling unit
|
Glycol water tank
|
1500L
|
1
|
|
Cooling compressor
|
8hp
|
1
|
|
Water pump
|
3 m³/h
|
1
|
|
CIP unit
|
Alkali tank
|
100L
|
1
|
|
Sterilization tank
|
100L
|
1
|
|
Pump
|
3 m³/h
|
1
|
|
Control unit
|
Siemens PLC/PID controlling system
|
1
|
|
Filter system
|
Kieselguhr filter machine
|
500L/H
|
1
|
|
Bright beer tank
|
1000L
|
1
|
|
Spare parts
|
All necessary spare parts such as pipes, valves, gauges and clamps…etc.
|
Optional:
1-mash/lauter tun, brew kettle/whirlpool, hot liquor tank
2- mash/brew kettle, lauter tun/whirlpool, hot liquor tank
3- mash/lauter tun, brew kettle, whirlpool
4- mash tun, lauter tun, brew kettle/whirlpool
5- mash tun, lauter tun, brew kettle, whirlpool
Main specifications of brewhouse and fermentation:
Brewhouse system:
1) - interior wall stainless steel 304, 3mm;
- exterior wall stainless steel 304, 2mm
2) -Dome top, top manway with glass
-Side manway, cone bottom 160 degree
3) - insulation: polyurethane/rockwool 100mm;
- with inside CIP washing ball
- agitator
- removable false bottom
- sparging arm, sight glass
-Tangential inlet for whirlpool
-Thermowell for temperature sensor and thermometer....
Fermentation system:
1) - Interior wall stainless steel 304, 3mm;
- exterior wall stainless steel 304, 2mm
2) -Dome top, conical bottom,
-Top manway
3) -Insulation: polyurethane 100mm
4) -Glycol cooling jackets on both cylinder and cone
5) - Inside 360 degree rotating CIP washing ball;
- CIP arm
- Bung apparatus
- safety&vacuum valve on top
-sample valve
- rotating racking arm
- thermometer
- dry hops port
-carbonation stone (optional)
6) -100% TIG welding with pure argon gas shield
-Interior Finish: Mirror polishing to 0.4~0.6μm without dead corner
-Testing pressure: 3 bar
- working pressure: 1.5-2 bar
OPTIONAL:
Beer bottling line: bottle washing machine; bottle filling&capping machine,
pasteurization tank, labelling machine.
Kegs washer and filler.
Beer kegs(10L,20L,30L,50L; 1/6bbl, 1/4bbl, 1/2bbl).
Steam boiler.
